Features and Benefits：

1. Compacter size than other connectors, 0.6mm pitch, 1.0mm thickness

2. 4X/6X(38pin) and 8X/12X(74pin) and 16X/20X(124pin) connectors are available

3. Low loss, optimized NEXT (-45dB at 12.89GHz) and FEXT (-40dB at 12.89GHz)

4. Support  UPI1.0 11.2GT/s, 25 Gbps signal rate(56G PAM4), SAS4.0 24Gbps and PCIe 4.0 16GT/s per lane

5. Impedance 85 ohm

6. Customized SI specification and length

7. 34-30AWG cables are optional

Applications：

1. Switch

2. Router

3. Base station

4. High end server

Product specification:

SAS4.0, PCIe4.0 and 25G/28G specification
