Applications

1.Data Storage

2.RAID (Redundant Array of Independent Disks )

3.Workstations

4.Rack-mount server

5.Servers

6.Storage rack

7.SolidStateDisk

Features and Benefits

1.Transmission rate 32GT/s PCIe Gen5.

2. Meet SAS4.0 specification.

Mechanical Performance

Mating Force and Unmating Force

Condition: EIA 364-13. Insert and extract at a speed of 25mm/minute.

Mating Force: 59 N maximum.

Unmating Force: 12 N minimum.

Electrical Performance

1.Contact Resistance

30mohm max. initial, 15mohm maximum after stress test.

2.Dielectric Withstanding Voltage

500 VAC for 1 minute no breakdown.

3.Insulation Resistance

1000 Mega ohms minimum.

Signal Integrity

Can meet PCIe Gen5 performance

Product Environmental Compliance

RoHS2.0: Compliant

ChinaRoHS: Yes

REACH SVHC: Yes
